Laboratory Stirrer RQ 5 Plus & RQ 100 Plus

Send Inquiry

Request To Call Back

Laboratory Stirrer RQ 5 Plus & RQ 100 Plus

Get a Price/Quote

MOQ : 1 Unit

Laboratory Stirrer RQ 5 Plus & RQ 100 Plus Specification

Speed Range
100-2200 RPM (stepless, variable)

Control Type
Digital speed control with timer

Shape
Rectangular base with vertical mainframe

Display Type
LED Digital Display

Accuracy
1% of indicated speed

Temperature Resistance
Ambient to 40C (operation)

Features
Continuous duty rating, Overload protection, Safety cut-off, Uniform stirring, Maintenance free

Power Supply
Single phase, AC supply

Type
Laboratory Stirrer

Dimension (L*W*H)
415 mm x 260 mm x 515 mm (approx.)

Equipment Type
Stirrer

Equipment Materials
MS powder coated body, Stainless Steel Shaft & Blades

Power
0.37 HP (for RQ 5 Plus), 1/6 HP (for RQ 100 Plus)

Voltage
220/230 V AC, 50/60 Hz

Material
Stainless Steel

Application
Mixing, Stirring, Homogenizing laboratory solutions and samples

Warranty
Yes

Capacity (Ltr)
2 to 25 liters (RQ 5 Plus), 2 to 100 liters (RQ 100 Plus)

Noise Level
< 65 dB

Stirring Shaft
Stainless steel, removable

Model Numbers
RQ 5 Plus & RQ 100 Plus

Motor Type
PMDC motor, high torque

Maximum Viscosity Handling
up to 40,000 mPas

Timer Function
Digital timer, 1-999 minutes

Blade Type
Stainless steel, propeller type

Mounting
Table top

Weight
Approx 10-15 Kg depending on model

Protection Features
Motor overload, short circuit protection

Laboratory Stirrer RQ 5 Plus & RQ 100 Plus Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID), Cheque, Cash Advance (CA)

Supply Ability
10 Units Per Day

Delivery Time
3 Week

Main Export Market(s)
Eastern Europe, Middle East, Central America, South America, Asia, Africa

Main Domestic Market
All India

About Laboratory Stirrer RQ 5 Plus & RQ 100 Plus

Laboratory Stirrer RQ 5 Plus & RQ 100 Plus

Salient Features

High torque even at low speeds
Monitoring of set & actual speed
Wide range of impellers
Advanced Stirrers with microprocessor technology
Advanced Stirring speed control through VFD
Constant speed even with change of load / Voltage
Easy -to- read display of set & actual parameters
Last parameter recall. Ideal for repetitive processes
Accepts shafts up to 13mm
Key less chuck
Motor protection in case of continuous overload
Stopper for protection of vessel & shaft
Special base design for topple free operation

Technical Specification

Features	RQ- 5 Plus	RQ-100 Plus
Max . Stirring capacity (water )(Liters)	5	100
Motor type	BLDC	AC induction, 3 phase
Motor rating	10 watt	100 watt
Speed range (rpm	50-1500	100-4000
Speed display	LED	LED
Timer	0 to 99 minutes	0 to 99 minutes
Motor overloaded protection	LED light flash ,auto stop	LED light flash ,auto stop
Chuck(mm)	1.5 x to 10	1.5 to 13
Stirring shaftx length (mm)	6 x 380 mm	12 x 500
Impeller type /(mm)	Axial turbine / 36	Pitched x 2 /65
Dimension (Wx Dx H) (mm)	80 x 180 x 370	320 x 285 x 620
Stand length (mm)	500	1220
Weight (kg)	6.5	19
Power (W)	10 watt	175 watt

Advanced Digital Controls for Precision Operation

Both the RQ 5 Plus and RQ 100 Plus laboratory stirrers feature an easy-to-use digital speed control and timer, allowing for precise adjustment and monitoring of stirring parameters. The LED display ensures clear readability, while the digital timer offers accuracy for time-dependent mixing tasks, ranging from 1 to 999 minutes.

High Efficiency and Safety Assured

Designed with a powerful PMDC motor, these stirrers provide high torque for uniform and efficient mixing across various viscosities up to 40,000 mPas. Built-in safety features such as motor overload and short circuit protection, along with a safety cut-off, ensure reliable and safe operation during continuous laboratory tasks.

Versatile Capacity and Durable Construction

Accommodating volumes from 2 up to 100 liters, these models are suited for both small- and large-scale laboratory processes. Constructed using stainless steel and an MS powder-coated body, the stirrers are resistant to corrosion and chemicals, ensuring long-term performance even in demanding environments.

FAQs of Laboratory Stirrer RQ 5 Plus & RQ 100 Plus:

Q: How do I set the stirring speed and timer on the RQ 5 Plus and RQ 100 Plus?

A: You can easily set both the stirring speed and the timer using the digital control panel on the front of the stirrer. The speed can be adjusted steplessly within the range of 100 to 2200 RPM, and the digital timer can be set anywhere between 1 and 999 minutes for precise operation.

Q: What types of solutions or samples can these laboratory stirrers handle?

A: The RQ 5 Plus and RQ 100 Plus are suitable for mixing, stirring, and homogenizing a wide variety of laboratory solutions and samples with viscosities up to 40,000 mPas. Their stainless steel propeller blades enable uniform mixing even for thicker or more viscous substances.

Q: When is the safety cut-off or overload protection activated?

A: The built-in safety cut-off and motor overload protection activate automatically if the stirrer detects excessive load, short circuit, or operational anomalies, ensuring motor longevity and user safety during continuous use.

Q: Where can these stirrers be installed in the laboratory?

A: These models are designed for table-top mounting, allowing installation on any stable laboratory bench or work table. Their rectangular base and vertical mainframe provide a compact yet sturdy platform for daily laboratory work.

Q: What benefits do the stainless steel shaft and blades offer?

A: Stainless steel construction ensures resistance to corrosion, chemical reactions, and general wear. This makes the stirrer durable, easy to clean, and suitable for handling a wide range of laboratory reagents and solutions.

Q: How does the digital accuracy benefit laboratory processes?

A: With 1% speed accuracy and a precise timer, you can achieve consistent and reproducible results for processes requiring exact mixing durations and speeds, enhancing the reliability of your experiments or sample preparations.
